Aquarius Mouse Trap 14ft

Availability: Product not in stock!

$ 160.00
LOA: 14'0m
Beam: 7'3"
Weight: 120lbs
Sail area: 95 sqft
Materials:
4 sheets 8 x 4x 3/16"ply;
4x14'6" of 1" x 5/8" Kauri or similar;
6ft 1"x 1 " and 6ft 3/4"x1/2" Kauri or similar; 6ft of 5x1/2" Kauri or similar;
70yds of 2 fibreglass tape;
1/2 gal. Epoxy resin;
Small quantity of loose chopped strand or mat

The MOUSE TRAP is a high performance 14ft catamaran constructed from fullsize plans using sheet ply to the latest construction techniques. The craft is constructed over a simple mould using sheet plywood planking with the seams glass taped thus eliminating the need for internal framework. This craft has sufficient buoyancy to sail well with up to 3081bs so proves ideal for father and son sailing.

The plan includes FULLSIZE PATTERNS of the frames and stem for the hull jig plus detailed working drawings.
